• TALENTO Warcom CNC control

Touch screen

Possibility to import DXF files

3D visualization

Colour graphic

Windows XP Professional

4 USB doors

Integrated CD reader

Bend simulator and optimizer

Intermediates clamp management – machine set up

• CE frontal support arms

All WARCOM standard press brakes come with N. 2 CE frontal support arms which are easily handled horizontally and vertically.The supports help the operator in handling bulky metal sheets. The elegant and essential design is another point in favour of WARCOM press brakes.

• Laser-Safe safety system

As its standard equipment, Warcom has chosen to use the “Lazer-Safe” safety system. High productivity, simple manipulation of the material and maximum safety for the operator, are the goals that a modern safety system for press brakes, is to satisfy, respecting the EC directives and standards at all times.
The operator’s safety is guaranteed by two laser beams which run under and with the top ram. The moment the first laser beam reaches the mute point, the ram slows down and descends at work speed.
The work speed of 10mm/s is reached when the ram is almost touching the tools blocking device.
FUNCTIONING PRINCIPLE
When one of the laser beam are obstructed (operator’s hand or sheet), the machine stops immediately. When obstacle is removed and after pressing the foot pedal again, the bending sequence can be completed. The so called “boxing” mode allows the production of boxes by interrupting the front and rear beams of the light guard; in such case the operator’s safety is guaranteed by the central laser beam which remains active and the geometry of the piece is still preserved.

• Heat exchanger

The hydraulic system of the bending machines is well-dimensioned and does not have overheating problems, not even in very hard work conditions. Despite of this, Warcom has still decided to install as a standard item a heat exchanger on all its machines, which is definitely a big help when machine will be working in environments with extreme high temperature or humidity or in case of robotised cells having higher speed and operating 3 shifts.

• Hydraulic dynamic crowning unit model DCS

Bending is a deformation physical process subject to remarkable spring backs and it can be influenced by many factors. The new DCS system (Dynamic crowning system) detects the minimum deformation of the structure in an absolute and not theoretical way and it compensates in real time thus guaranteeing an excellent bending result both in precision and parallelism.
The “DCS plus” version represents a further upgrade of the system; it integrates the active dynamic crowning with pressure sensors capable of determining the exact thickness, resistance and length of the material. These values are automatically recalculated without reprogramming the CNC, optimising thus the result of the bends.

• Twin roll-ram guiding
