milling supermax series ycm 180 cnc with fixed table fanuc 0-m refurbished used

Comments Off on milling supermax series ycm 180 cnc with fixed table fanuc 0-m refurbished used Stock Removal, Used Machines

Technical Data:
Race for the longitudinal axis X 1800 mm
Cross travel Y-axis ram 740 mm
Vertical travel Z axis 900 mm
Light spindle nose to table surface mm  167 – 1067
Table surface 2000-600 mm
T-slots Mm  20 (H8) x5x100
Maximum flow rate 2000 kg
Engine power A.C. motor power modle 22P
11 kw (cont.) 15 kW (30 min.)
Spindle speed 21-2250 rpm (2 shifts)
Transmission range yes
Rapid axis X, Y, X, Y: 9m/min
Fast Z-axis Z: 6m/min
Machine weight kg 13700
Toolholder BT50 + MAS P50T-Type-I HURON
Data must be verified
