machining center iron center machine series a-v450 mini high speed
V450 Specifications
| Table | Working surface | 355 x 610 mm |
| T slot | 14 mm x 100 mmx 3 | |
| Loads Capacity | 150 KGS | |
| Travel | Stroke(X x Y x Z ) | 450 x 350 x 350 mm (Z 410mm) |
| Center to Column | 410 mm | |
| Nose to Table | 160 – 560 mm | |
| Spindle | Spindle Table | BT30 (BT40) |
| Spindle Speed | 10,000 RPM (8,000/12,000/24,000 RPM) | |
| Spindle Horse Power | 5 HP (7.5 HP ) | |
| Transverse | Rapid X,Y axis | 20 M/Min |
| Rapid Z axis | 10 M/Min (20 M/Min ) | |
| Max. Feed | 10 M/Min | |
| Servo Motor Power | 1 KW (2 KW ) | |
| Accuracy | Positioning accuracy | + / -5um |
| Repeatability | 2um | |
| Machine | Dimension W x D x H | 1500 x 2000 x 1950 |
| Weight | 2800 KGS | |
| Power Source | 15 KVA |
| Standard Accessories | Optional Accessories |
| 1.Tools box | 1.Rigid Tapping |
| 2.Automatic lubrication system | 2.BT40 – 12,000 RPM |
| 3.Full close cover | 3.BT30 – 24,000 RPM |
| 4.Work lamp and alarm lamp | 4.Rotary table 125mm |
| 5.Arm Type 20/16 tools ATC | |
| 6.Hard driver | |
| 7.Ethernet | |
| 8.Five axis table 125mm | |
| 9.Coolant Through Spindle device | |
| 10.Tool Length Setter. |
